New ASTM Standard Practice for Matrix Array UT (MAUT)
Posted: 2023-4-26
In response to growing demand for Matrix Array UT (MAUT) standards, ASTM International have recently published E3370-22, "Standard Practice for Matrix Array Ultrasonic Testing of Composites, Sandwich Core Constructions, and Metals used in Aerospace Applications". The Standard has its origins in ASTM E2580-17 "Standard Practice for Ultrasonic Testing of Flat Panel Composites and Sandwich Core Materials used in Aerospace Applications", which is intended for use with single element transducers. The new E3370-22 is instead designed specifically for use with non-phased, matrix array transducers such as the Dolphicam2 platform, manufactured by Dolphitech. Such transducers operate with an isotropic matrix array of elements with a small pitch and high count (eg 128 x128 elements at 0.25mm pitch), operating in straight beam (ie 0°) mode. As such, they are unique in being capable of live C-scan generation.
As it sits between conventional straight beam UT and Phased Array, MAUT has previously been underrepresented by international standards. Dolphitech Defense CEO Jason Smith comments "We are delighted by the publication of this standard by ASTM International. It provides our customers with a great starting point for building their own inspection procedures, through detailing all aspects that need to be considered. This document will also pave the way for further matrix array UT standards, with ASME and ISO standards already in the pipeline."
The Standard itself covers two modes of operation, Test Procedure A: Pulse Echo, and Test Procedure B, Through Transmission. In addition, general considerations such as quality assurance provisions, test apparatus, physical reference standards, and reporting requirements are all discussed in detail. Jack Lambert, Technical Sales Manager at Dolphitech Ltd, comments "It is fantastic to see new technology such as matrix array UT being detailed as an ASTM Standard Practice. As well as providing new and existing users of this technique with a useful guide, documents such as E3370-22 are vital in ensuring that the international standardization effort keeps up to date with emerging technologies and thus stays relevant to industry practices."
For more information and to purchase the Standard, please visit https://www.astm.org/e3370- 22.html.
Get in touch with Dolphitech to learn more about the Dolphicam2 platform.
About Dolphiteh
Dolphitech is a pioneer in the next-generation ultrasonic technology for non destructive testing. The company is recognised worldwide for high-quality ultrasonic non-destructive testing products, utilising unbeatable ultrasonic matrix imaging technology to inspect and detect damage, degradation, and defects in mission-critical assets across various industries. Dolphitech delivers a cutting-edge inspection platform to improve measurable efficiencies in testing, production processes and costs.
Originating out of Norway’s leading industrial-technology cluster, the company has grown significantly, becoming an established technology leader in industrial ultrasonic NDT equipment. Dolphitech employs a team of multi-skilled R&D and engineering experts with diverse backgrounds in academia and industry. Dolphitech continuously investigates the capability and application of advanced ultrasonics, bringing proven solutions to the market that are easy to deploy and operate globally.
For more information visit www.dolphitech.com
